Automatic Carton Sticker Labeling Machine

Automatic Electronic Liquid Filling Machine is highly efficient Machine with Elegant Look. This is High speed and flexible filler capacity of filling rapidly and accurately any type of Liquid.

Multipurpose machine meets custom requirements of Filling for PET, Glass, HDPE and Aluminum Bottles. This machine is manufactured with Stainless Steel SS-304 and World class quality Automation Equipment.

This machine is coming with own pumping system to collect the liquid from main Tanks. The Flow will be measured using Automation system and converted in digital signals that can be controlled by PLC and HMI.

While changing different volumes, it takes minimum time to setup the system as per requirements.

Numbers of recipe can be set on the same screen without changing parts.

The conveyor is driven by Induction motor and Pneumatic system will arrange bottles below filling nozzles. Filling System is synchronized with Conveyor system which is controlled by PLC so that you can set Speed by terms of Bottles per minute.

It is user friendly, low maintenance and High Speed machine.

Free Quote

Your Name

Email address

Phone Number

Location

Requirement

Technical Parameters

Brand Name
Type
Output Per min
Packaging Types
Construction Material
Direction of Movement
Power supply
Number of Head
Suitable Products

Shiv Engineering
Filling System
Up to 30 BPM
Bottles
SS-304
Left to Right
Single phase, 220V, 50 Hz (Depends on req.)
4 to 12 Heads
Any type of Non-Acidic Liquid

Certifications
Machine Dimension
Filling range
Accuracy
Operation
Air Required
Application
Machine Weight
Warranty

CE and ISO Certified
L 2500 x W 850 x H 1800 mm
50 to 5000 ml
+/- 1% Depends on Type of Liquid
Full Touch Panel with Color Display
4-5 CFM with 6 Bar pressure Filters and Regulators
Pharmaceuticals, Edible oils, Lube Oils, Chemicals, Pesticides and Agrochemicals, Cosmetics and FMCG etc.
400 kg approx
1 Year

Salient Features

1 Automatic Electronic Liquid Filling Machine
2 No Bottle No Filling
3 7 Inch Full Touch Color Display with more than 50 recipe Storage
4 High Repeatable Accuracy
5 Inbuilt pump System
6 No intermediate tank needed
7 Drip Free nozzles for Clean Products Conveying
8 Individual Measurement for each head of filling

9 Automatic Electronic Liquid Filling Machine
10 No Bottle No Filling
11 7 Inch Full Touch Color Display with more than 50 recipe Storage
12 High Repeatable Accuracy
13 Inbuilt pump System
14 No intermediate tank needed
15 Drip Free nozzles for Clean Products Conveying
16 Individual Measurement for each head of filling
